Lepidoptera Biodiversity LLC



Genitalia image sets for selected dissection voucher specimens of Coxina (Noctuidae: Erebinae)



Updated July 2015



Genitalia were dissected and images taken by Hugo L. Kons Jr.  Images were taken with the GT Vision imaging system {GT} at the American Entomological Institute or the Automontage imaging system {AM} at the University of Wisconsin-Madison Department of Entomology.  All structures are the natural three dimensional shape (not slide mounted) except for the juxta/anellus and abdominal cuticle (temporarily slide mounted for imaging).



Note:  The left links are pdfs that should work with any internet browser.  The right links (available for some of the below) are power point web pages that only work correctly with microsoft internet explorer.







"Coxina" hadenoides ♂ {GT} [Dissection No.: 2013HLK:1904; DNA No.: 3551-COI-08] pdf             ppt web page





"Coxina" hadenoides ♀ {GT} [Dissection No.: 2013HLK:1905; DNA No.: 3553-COI-08] pdf             ppt web page





Note: Coxina hadenoides occurs in the lower Rio Grande Valley of southern Texas.  It closely resembles the more widespread and sympatric Heteranassa mima in wing pattern and had been mixed with H. mima in collections, but genitalia and COI 5' both suggest the two species are not closely related.  Heteranassa mima has the two anterior loops of the postmedial line extending about the same distance distally, whereas in C. hadenoides the posterior of the two loops extends much farther distally (see red arrows below).  The color and contrast of H. mima is variable and often similar to C. hadenoides where they fly together in south Texas.  Coxina cinctipalpis has less light contrast in the medial and subterminal areas relative to C. hadenoides.  The type of Coxina hadenoides was examined from a photo provided by Don Lafontaine (July 2015).  In the U.S. this name had previously been applied incorrectly to a dark form of Coxina cinctipalpis with a contrasting white patch basal to the loop of the postmedial line (bottom left in below photo).  The name was also being applied to another species in Costa Rica.



compare





Strict consensus tree of "Coxina" and Heteranassa COI 5' sequences in the Kons and Borth BOLD projects

Heteranassa2 bs 100 times
